Wire for 0-5V output

Written By: StJohn Vuetilovoni (and one other contributor)
  • Comments: 0
  • Favorites: 0
  • Completions: 2

Difficulty

Moderate

Steps

3

Time Required

Suggest a time??

Sections

1

Flags

0

  1. To understand analog output, read 0-5V analog output.

  2. The external connector requires an RJ12 connector. The pin designations for the external output connector are numbered 1 to 6. 1 = 12VDC (closest to the 12V DC power jack)

    • The external connector requires an RJ12 connector. The pin designations for the external output connector are numbered 1 to 6.

    • 1 = 12VDC (closest to the 12V DC power jack)

    • 2 = Analogue output 0-5V

    • 3 = Control

    • 4 = High alarm

    • 5 = Low alarm

    • 6 = Ground (furthest from the 12V DC power jack)

  3. Wire at pins:

    • Wire at pins:

    • 2 (Analogue output 0-5V)

    • 6 (Ground).

Conclusion

For further support, contact Technical Support.
