Introduction

If the correct flow rate can’t be achieved through a gas module, this may indicate a leak. A gas module can be checked for leaks by using a small diaphragm pump and a flowmeter.

To understand how often you should perform this service activity, click here.

Tools

No tools specified.

  1. Enter service mode so any fluctuations in the data caused from this activity can be excluded from air quality reports.
    • Enter service mode so any fluctuations in the data caused from this activity can be excluded from air quality reports.

  2. Attach a small diaphragm pump  to the module's gas outlet (exhaust).
    • Attach a small diaphragm pump to the module's gas outlet (exhaust).

    • Connect the exhaust of the diaphragm pump to a flowmeter. The flow should read about 2.O LPM.

    • Disconnect the sample line from the module's inlet port and insert a luer cap.

    • You should see the flowmeter drop to zero. If it doesn’t, there’s a leak somewhere.

    • If you find the module has a leak, contact Technical Support.

Conclusion

For further support, contact Technical Support.
